第31卷第15期農業工程學報Vol.3l No.152162015年8月Transactions of the Chinese Society of Agricultural EngineeringAug. 2015無軸螺旋連續熱解裝置上的生物質熱解特性王明峰，吳宇健，蔣恩臣*，陳曉塹(華南農業大學材料與能源學院，廣州510642)摘要:連續熱解是--種高效的生物質能轉化技術，無軸螺旋式連續熱解裝置不僅可減輕送料部件的質量，而且為熱解揮發性產物的排出提供了有效空間，是極具發展前景的連續熱解裝置。為了解無軸螺旋式生物質連續熱解特性，該文在無軸螺旋連續熱解裝置上，開展了以稻殼、花生殼和木薯莖稈為生物質原料的熱解試驗，分析了3種生物質在不同熱解溫度下的三態產物分布特性、熱解氣體組分變化規律及熱解炭的組織結構和表面形貌特征。結果表明:炭產率隨熱解溫度升高逐漸下降，氣體產率逐漸上升，液體產率先上升再下降，在450C時達到最大，產物分布特性與其他熱解反應器的一-致:不同原料炭產率由高到低依次為:稻殼>花生殼>木薯莖稈，液體產率由高到低依次為:稻殼>花生殼>木薯莖稈，氣體產率與液體產率相反。熱解氣體組分受溫度影響較大，熱解溫度升高，可燃?xì)怏w組分含量不斷上升，不可燃?xì)怏w組分含量不斷下降，不同原料對氣體組分含量影響較小。熱解炭的工業分析結果與原料的工業分析結果存在相關性，熱解溫度升高，熱解炭中揮發分含量逐漸下降，固定碳及灰分含量增加，木薯莖稈炭的揮發分含量最高，花生殼炭的固定碳含量最高，稻殼炭的灰分含量最高;低溫?zé)峤馓康谋砻婀倌軋F(tuán)較為豐富，隨熱解溫度升高官能團種類逐漸減少:原料自身結構特性對熱解炭的表面形貌影響較大，隨著熱解溫度升高，生物質原料的表面結構不斷被破壞，熱解炭表面出現孔隙結構，花生殼炭與木薯莖稈炭表面孔隙結構比稻殼炭更為發達。關鍵詞:生物質;熱解;秸稈;無軸螺旋連續熱解裝置;產物分布;熱解氣組分;熱解炭特性doi: 10.11975/j.issn.1002- 6819.2015.15.030中圖分類號: TK 62文獻標志碼: A文章編號: 1002- 6819(2015)-15 -0216- 07王明峰，吳宇健，蔣恩臣，陳曉塹.無軸螺旋連續熱解裝置上的生物質熱解特性[J].農業工程學報， 2015， 31(15):216- 222. doi: 10.1175/.issn.1002- 6819.2015.15.030htp://www.tcsae.orgWang Mingfeng, Wu Yujian, Jiang Enchen, Chen Xiaokun. Biomass continuous pyrolysis characteristics on shaftless screwconveying reactor[J]. Transactions of the Chinese Society of Agricultural Engineering (Transactions of the CSAE), 2015, 31(15):216 - 222. (in Chinese with English abstract)doi: 10.11975/jissn. 1002-68 19.2015.15.030http://www.tcsae. .org文獻[8]、[9]、 [10]在螺旋送料式連續熱解裝置上0引言對玉米秸稈、小麥秸稈和稻殼進行了熱解特性研究，中國當前面臨著能源枯竭與環境污染的雙重危機，開表明，已有連續熱解設備能夠?qū)⑸镔|(zhì)原料轉化生成發新的潔凈可再生能源受到廣泛的關注，其中生物質能作炭、生物油和熱解氣，在一定范圍內隨著熱解溫度的為- -種含能體能源，是清潔豐富的可再生能源"，而中國升高，炭產率下降，氣體產率上升，液體產率先升高農業生產剩余物尚缺乏有效的回收利用途徑，開展農業生后降低。連續熱解的生物炭產率在34% ~42%之間;物質的開發利用研究具有深刻的意義和廣闊的前景。生物油產率在35%左右，包括焦油和木醋液兩部分，熱解:是生物質能的一-種 重要利用形式，是指生物質主要組分為酸、醇、酮、酚等有機物;熱解氣產率在.原料在隔絕或者低氧的環境下受熱裂解的過程，主要生17%~23%之間，成分主要包括: H2、 CO2、CO、CH4成固體炭、可冷凝液體油和可燃?xì)怏w產物123。生物質連及其他ChHm等。續熱解是-一種高效的熱解處理方式，受到國內外研究學與現有的螺旋式連續熱解裝置相比，無軸螺旋式連者的重視，英國利茲大學及國內的華南農業大學、山東續熱解裝置不僅可減輕送料部件的質量，而且為熱解揮省能源研究所、中科院蘭州化學物理研究所和浙江大學發性產物的排出提供了有效空間，是極具發展前景的連等科研單位開展了以螺旋輸送器為核心部件的生物質連續熱解裝置。目前，針對無軸螺旋式生物質連續熱解特續熱解裝置的研究工作[47。性的研究較少。本文在自行研制的以無軸螺旋送料器為核心部件的連續熱解反應器上，開展了具有代表性的3種生物質稻殼、花生殼和木薯莖稈的熱解試驗，分析生收稿日期: 2015-05-04 修訂 日期: 2015-07-14基金項目:科技部農業科技成果轉化資金項目(2014G2000048); 土壤植物質原料的組分差異和熱解溫度對三態產物分布、熱解物機器系統技術國家重點實驗室開放課題(2014-SKL-07)氣體組分變化規律及熱解炭的組織結構和表面形貌的影作者簡介:王明峰，男，遼寧鞍山人，講師，主要從事生物質能利用研究。響，并與已有熱解炭化技術進行對比，探討裝置的適應州華南農業大學材料與能源學院，510642。 Email: wangnmingfeng@scau.edu.n性，為不同生物質原料連續熱解工藝參數的確定和熱解※通信作者:蔣思臣，男，黑龍江，教授，博士生導師，主要從事生物質能產物利用提供理論基礎。利用工程研究。廣州華南農業大學材料 與能源學院，510642。Email: ecjiang @ scau.edu.cn第15期王明峰等:無軸螺旋連續熱解裝置上的生物質熱解特性2171原料與裝置木科作物莖稈，纖維素、木質素含量較為豐富。試驗用稻殼、花生殼和木薯莖稈分別購自于廣州某稻谷加工廠、江1.1 原料本試驗以3種代表性農業生物質稻殼、花生殼和木薯蘇-植物肥料中心和廣西的木薯生產基地，原料經粉碎后莖稈為原料，其組分分析1-31見表1,其中，稻殼是禾本科在70'C電熱恒溫干燥箱內烘干24h,統- -過 40目篩后裝袋植物外殼，主要含有纖維素、半纖維素成分;花生殼是豆密封，其工業分析結果見表1,工業分析方法參考國標科草本植物外殼，主要成分為木質素;木薯莖稈是大戟灌GB/T287312012固體生物質燃料工業分析方法。表1原料組分分析與工業分析Table 1 Proportion of three-component and proximate analysis of biomass materials9組分分析Three component analysis工業分析Proximate analysis原料纖維素木質素水分揮發分灰分固定碳MaterialsCelluloseHemicelluloseLigninMoistureVolatileAshFixed carbon稻殼21.9019.0017.806.4568.5011.3813.6Rice husk化生元..16.9110.1027.436.0372.733.8717.3Cassavastalk34.3723.8136.258.076.394.511.081.2試驗裝置VERTEX70型紅外光譜儀分析表面官能團、利用荷蘭FEI試驗用無軸螺旋連續熱解裝置見圖1。熱解裝置由送公司XL-30-ESEM型掃描電鏡觀察表面形貌，熱解氣體料系統、熱解反應系統和冷凝收集系統組成，包括調速組分含量利用安捷倫GC6820氣相色譜儀進行檢測。電機、進料漏斗、無軸螺旋輸送器、熱解爐體，溫控器、2結果與討論炭箱、冷凝管等主要部件。2.1無軸螺旋連續熱解裝置的冷態輸送特性在常溫下開展無軸螺旋連續熱解裝置的冷態輸送特性試驗研究，控制驅動電機轉速，保證物料在熱解管內停留時間為8 min,試驗進行30 min后停止，統計管路內口wwwwwwww10叮殘留生物質原料質量，結果見表2。14表2冷態試驗管內物料殘留量1.調速器2.驅動電動機 3.聯軸器4.進料斗.熱解反應器6.無車6.無軸螺旋輸Table 2 Residues of materials at normal temperature experiment送器7.,加熱爐 8.炭箱 9.出氣口10.冷凝管 1.伴熱帶 12.氣體回?zé)螹aterials殘留量Residues/g13.伴熱帶溫控器14.爐體支架 15.爐體溫控器 16.電機支架 17.集氣閥稻殼Rice husk9.8花生殼Peanut shell9. Gas outlet 10.Condenser tube 1 I .Heating belt 12 .Gas buming pipe木薯莖稈Cassava stalk24.813.Heating belt controller 14.Frame of heating furmace 15.Heating furnacecontroller 16.Frame of motor 17.Gas collection valve注:熱解管內原料停留時間為8 min,下同。圖1生物質無軸螺旋連續 熱解裝置Note: Conveying residence time is 8min. The same as below.Fig.1 Sketch of biomass continuous pyrolysis reactor熱解管內物料輸送存在死角，物料在進料口附近區裝置工作原理如下:粉末狀生物質原料經由進料漏域形成殘留，不同原料的物料殘留量不同。冷態試驗中斗送入熱解反應管，由電機帶動無軸螺旋輸送器將物料木薯莖稈殘留量最大，花生殼次之，稻殼殘留量最小。推送至熱解反應器的高溫反應區，物料在推送過程中完稻殼是禾本科纖維植物外殼，粉碎后更多呈現細密條狀，成熱解，生成的熱解炭落入保溫炭箱，熱解揮發物通過螺旋推送時物料間作用力更大，有利于完全送料。而花炭箱出氣口進入冷凝系統，液體產物被冷凝收集，不可生殼、木薯莖稈中木質素成分較高，粉碎后更多呈現較冷凝氣體引至炭箱底部點燃，保證炭箱溫度大于200"C,小的細片狀或顆粒狀，物料間作用力作用小，易滯留在管底，導致殘留量增大。防止熱解揮發物在炭箱內冷凝。1.3 試驗方法2.2連續熱解三態產率分析連續熱解試驗反應溫度梯度為350、450、550、650"C，稻殼、花生殼和木薯莖稈連續熱解三態產率及管內熱解反應時間8 min，炭箱升溫至200"C保溫，采用4組殘留量見表3，其中炭產率、液體產率和管內殘留率通過冷凝管對熱解揮發物進行冷卻，冷卻水溫度為25C，試稱量法獲得，氣體產率通過差減法求得。熱解條件下，驗中采用集氣袋收集部分不可冷凝氣體用于檢測。試驗管內物料殘留量大小順序與冷態試驗相同，但熱解生成結束后，統計熱解炭、液產物及管路殘留物料的質量。的焦油氣回滲與原料混合，使原料更易粘附在無軸螺旋原料及熱解炭表征方法:利用長沙友欣YX-GYFX 7701上，導致熱解條件下的殘留量略高。三態產物分布結果型全自動工業分析儀進行工業分析、利用布魯克表明，熱解溫度升高后，原料中揮發分的析出量增大，218農業工程學報tp://www.tcsae.org)2015年固體產物質量減小，導致炭產率不斷下降141。不同原料不同原料對氣液兩相產率影響較大。液體產率由高連續熱解炭產率存在一定差別，稻殼與花生殼炭產率較到低依次為:稻殼>花生殼>木薯莖稈，氣體產率與液為接近，木薯莖稈最低。稻殼中灰分與固定碳含量之和體產率相反。這2部分產物主要由原料水分及揮發分生最大，達25.04%，熱解后主要存留于固體產物中，對炭成，其中揮發分起主導作用，由原料工業分析數據可見，產率貢獻較大，炭產率最高;花生殼兩者含量之和為3種原料中，木薯莖稈熱解生成的揮發性產物較多，且更21.24%，炭產率次之;而木薯莖稈兩者含量之和僅為容易發生二次裂解，利于生成氣體產物;稻殼熱解生成15.59%，且揮發分含量最高，對揮發性物質產率貢獻較的揮發性產物較少且不利于二次裂解反應，因而更多地大，導致其炭產率最低。生成液體產物;花生殼則介于兩者之間。生物質熱解產物分布特性很大程度上是由熱解條件表3原料連續熱解三態產率及管內物料殘留量(主要是熱解溫度)和原料的性質造成的16-181。盡管生物Table 3 Charcoal, liquid and gas yield of continuous pyrolysismaterials and residues in tube質原料特性和反應溫度有一-定的區別，但是熱解產物得原料Temperature/溫度炭產率液體產率氣體產率殘留量率的變化規律基本-致。文獻[19]和[20]在固 定床熱解反Yieldof Yieldof YieldofMaterials C“ “”charcoal/Residues/g應器上的研究表明，隨溫度的升高，可燃?xì)夂鸵合嗬淠齦iquid/% fuelgas/%物的產率增大，而熱解炭產率減小。生物質在無軸螺旋35041.1227.3329.1311.0連續熱解裝置上的熱解產物分布特性與其他熱解反應器留殼33.6635.2428.5911.4Rice husk5531.3731.9434.2511.1的一致。6528.2640.1.62.3連續熱解氣體產物特性35.5930.8429.020.5花生殼生物質連續熱解氣體組分含量見圖2。生物質原料中C45033.433.04>.23Peanut ;.6318.1元素比例最大，熱解生成的氣體主要由CO2和CO組成2，shell55027.8228.5726.7723.7445.0520.2此外還含有可燃?xì)怏wH2、CH、CH4等。熱解氣體組分3528.3926.437.544.7受溫度影響較大，隨著熱解溫度升高，CO2含量下降，木薯莖稈4524.6319430.6550"C連續熱解CO2相對含量約為35%，650"C連續熱解Cassava22.1444.sta19.722.0351.928.6時則都低于30%; H2含量明顯上升且增幅顯著，與CO2存在競爭關系，650"C 熱解時H2相對含量達20%~ 25%，氣液兩相產率呈競爭趨勢。熱解溫度升高，液體產率文獻[22]進行的玉米秸稈與稻殼熱解試驗同樣表明:當溫先升后降，在450°C時達到最大，此時，稻殼、花生殼和度從400C增加到600'C，H2相對含量顯著升高，從4%木薯莖稈的液體產率分別為35.24%、33.04%和31.94%;升到28%，與本文研究結果相近: CO含量略微下降，總氣體產率則相反，先略微下降再上升，在450"C時最小。體上保持穩定數值; CH4 含量先升高后穩定，350"C低溫450^C的熱解溫度為氣液產物競爭的分水嶺。研究表明，熱解產生甲烷較少，450"C后 保持相近數值，占15%~熱解溫度高于450°C時，會加劇液體產物二次裂解，生成20%; CH4含量逐漸升高，但含量較低。因此，隨著熱氣體產物，導致液體產率下降。因此，欲獲得液體產物，解溫度升高，熱解氣體產物中可燃?xì)怏w組分含量不斷升熱解反應溫度應控制在450"C附近;欲獲得氣體產物，應高，不可燃?xì)怏w組分含量不斷下降，高溫連續熱解不僅進一步提高熱解溫度，增加液體產物的二次裂解!5。有利于氣體產物生成，而且能夠提高氣體品質23-251。熱解溫度Pyrolysis temperature/rC23508 450日 550o 65070r60of三400出30口830f; 30一美自20-山小H,COCH,CO,CH售HcoCH。Co,CH,H co CH. CO2 CH，a. Rice huskb. Peanut shellC. Cassava stalk圖2生物質連續熱解氣體組分含量Fig.2 Gas composition of biomass continuous pyrolysis不同熱解溫度下，3種原料的熱解氣組分變化趨勢基約占25%，可燃?xì)怏w相對含量達到75%。本一致，熱解原料對氣體組分含量影響不大，在試驗熱2. 4連續熱解 炭特性分析解溫度范圍內，同一熱解溫度 下不同原料各熱解氣組分2.4.1連續 熱解炭的工業分析含量差別小于5%，相差不大，在650"C下3種原料的熱連續熱解炭工業分析見表4。熱解炭中固定碳含量最解氣中H2約占25%、CO約占30%、CH4約占20%、CO2高，是熱解炭的主要結構成分。隨著熱解溫度升高，熱第15期王明峰等:無軸螺旋連續熱解裝置上的生物質熱解特性219解程度加深，生物質中揮發分不斷分解析出，獲得的熱同原料熱解炭的官能團豐富度存在一定差異， 花生殼炭解炭的產率不斷減小:而灰分及固定碳大部分存留于熱的表面官能團較豐富，稻殼炭表面官能團較少。解炭中，其占總體比例逐漸增大，導致熱解炭中揮發分100百分含量逐漸下降，灰分及固定碳百分含量上升。550c-n 650C表4生物質熱解炭工業分析冒8450-/青7(Table 4 Proximate analysis of bio-charcoal from continuous查60-pyrolysisMaterials原料Temperature/Volatil/% Ash/% Fixed carbon/%揮發分固定碳器40個竹行5028.6726.7641.2800000000200050010000 5o00稻殼炭45016.6331.5748.09波長Wave length/em"Rice huskcharcoalso012.7349.22a.稻殼炭a. Rice husk biochar6509.2436.6450.2835034.755.1花生殼炭23.94765.7780-550C-Peanut shell55017.6911.32oof13.6274.24450UNV器路39.5813.2340.46exx三2號木薯莖稈炭4525.1117.12Cassava stalks518.0518.584000 3500 3000 2300 2000 1500 1000 500波長Wave length/cm'6517.0720.8855.33b.花生殼炭b. Peanut shell biochar不同生物質熱解炭的工業分析存在差異，并與原料的工業分析結果相關。3種熱鮃炎的固定碳含量由高到低資9-650C依次為:花生殼炭>木薯莖稈炭>稻殼炭，揮發分含量由801s50C-高到低依次為:木薯莖稈炭>花生炭殼>稻殼炭，灰分含450C-量由高到低依次為:稻殼炭>木薯莖稈炭>花生殼炭。稻60殼炭中固定碳含量低于木薯莖稈炭，主要是由于稻殼炭.|的灰分含量較高，占總體比例過大，導致其固定碳含量4000350030002500200015001000 - 5002.4.2連續 熱解炭表面官能團特性波長Wave length/em'450、 550、650C熱解溫度下獲得的3種原料熱解炭:木薯莖稈炭c. Cassava stalk biochar的紅外光譜(FT-IR) 檢測結果見圖3。圖3生物質熱解炭紅外圖譜450C熱解炭中,3 392 cm'處的吸收峰主要是分子.Fig.3 FT-IR spectra of bio-charcoal之間氫鍵締合的醇、酚的一_OH伸縮振動，表明存在酚2.4.3連續 熱解炭表面形貌特性羥基或醇羥基結構: 2958、 2921 cem'處的吸收峰主要是烷烴中的C- H的伸縮振動; s50、650C熱解炭在此3種原料及其350、 450、 550、 650'C熱解炭的掃描3個波數下的吸收峰消失。表明，隨著熱解溫度升高，電鏡(SEM)表征結果如圖4,放大倍數為1600倍。熱解炭中的一OH基團和_ CH2基團隨揮發物的析出而由SEM圖像可見，生物質原料表面結構較為平消失，生成CH4、CH、C2H6 等氣態烴!201。1415~整，經熱解后，表面結構被破壞，部分區域塌陷形成1694cm'為- C=C和C=O振動峰，表明生物質炭表面了凹凸不平的表面形態，隨著熱解溫度繼續升高，產含有羧基、羰基等酸性含氧官能團，此處峰面積減小，生了明顯的孔隙結構。生物質原料高溫?zé)峤夂?，其中該類官能團不斷減少。1 095 cm'處吸收峰是酚、醚、的有機質被逐漸分解，殘余的細胞結構形成了炭的孔醇的一C=O伸縮振動及一C=C 伸縮和一OH 面外彎曲腺結構，溫度越高，表面結構變化越明顯，大孔開始振動吸收峰，874、 794cm' 為芳香族化合物C-H變膨脹，并發育出更多的微孔結構126。不同原料熱解炭形振動吸收峰，此處峰面積逐漸增大，表明隨熱解溫度的表面形貌差異較大，花生殼炭與木薯莖稈炭表面孔升高，熱解炭縮合度上升，結構高度芳香化，逐漸形成隙結構比稻殼炭更為發達，主要是由原料自身結構特芳香化炭結構127-281。性造成的:花生殼本身具有起伏的表面結構，木薯莖低溫?zé)峤馍镔|(zhì)炭中各類官能團較為豐富，隨熱解稈內部為蓬松的絮狀結構，這些原料特性更有利于熱溫度升高，高波段的紅外吸收峰消失，官能團種類逐漸解炭孔腺生成，而稻殼的表面結構并不發達，不利于減少，芳香化炭結構逐漸增多。在相同熱解溫度下， 不熱解生成孔隙結構。220農業工程學報http://www.tcsae.org)2015年20 Jor20/ma.650C Rice husk Charcoal b. 650C Peanutshelichaharcoal 。650CCassavastalikcharcoald.350CRicehuskcharcoale 3soCPeanushellCharcoalRice husk charcob.650C Peanut shellcharcoal C. 650C Cassava stalk charcoalL520 Kice husk charcoale. 350C Peanut shell ch201m20 220 pm_f. 350C木薯莖稈炭g稻殼原料h.花生殼原料i木薯莖稈原料f. 350C Cassava stalk charcoalg. Rice huskh. Peanut shelli. Cassava stalk圖4生物質原料及不同溫度熱解炭SEM圖( 1600X )Fig.4 SEM images of bio-materials and charcoal in different pyrolytic termperature (1600X)trends of biomass pyrolysis technology[D]. Industrial Boiler,3結論2011(2): 10- 14. (in Chinese with English abstract)1)隨著連續熱解溫度升高，炭產率逐漸下降，液體3] Demirbas A. Biomass resource facilities and biomass產率先升后降，在450"C時達到最大，稻殼、花生殼和木conversion processing for fuels and chemicals[J]. Energy薯莖稈的液體產率分別為35.24%、33.04%和31.94%,氣Conversion & Management, 2001, 42(11): 1357- 1378.體產率與液體產率呈競爭關系。生物質在無軸螺旋連續4] Chidi E Efika, Chunfei Wu, Paul T Williams. Syngas熱解裝置上的熱解產物分布特性與其他熱解反應器的一production from pyrolysis-catalytic steam reforming of waste致。熱解氣體主要由CO2和可燃?xì)怏wCO、H2、CH4、CH4biomass in a continuous screw kiln reactor[J]. Journal of組成，隨著熱解溫度升高，可燃?xì)怏w組分含量上升，不Analytical and Applied Pyrolysis, 2012, 95(5): 87-94.可燃?xì)怏w組分含量下降，650°C 連續熱解可燃?xì)怏w相對含5] 蔣恩臣，蘇旭林，王明峰，等，生物質連續熱解反應裝置量達75%。熱解氣體組份含量受溫度影響較大，受原料的變螺距螺旋輸送器設計[D].農業機械學報, 2013, 44(2): .影響不大。121- 124.2)熱解炭工業分析結果表明，隨著熱解溫度升高，Jiang Enchen, Su Xulin, Wang Mingfeng, et al. Design of揮發分含量逐漸下降，灰分及固定碳含量上升。不同原variable pitch spiral conveyor for biomass continuous料的熱解炭工業分析存在差異，且與原料的工業分析結pyrolysis reactor[J]. Transactions of the Chinese Society for果存在相關性。Agricultural Machinery, 2013, 44(2): 121 : - 124. (in Chinese3)熱解炭紅外光譜分析結果表明:隨著熱解溫度升with English abstract)高，熱解炭逐漸形成芳香結構，縮合度上升，官能團種6] 王天崗，孫立，張曉東，等生物質熱解釋氫的實驗研究[D].類逐漸減少。同-一熱解溫度，不同原料熱解炭的官能團山東理工大學學報:自然科學版，2006， 20(5): 41-43. .豐富度存在差異，花生殼炭的表面官能團較豐富，稻殼Wang Tiangang, Sun Li, Zhang Xiaodong, et al. The study of炭表面官能團較少。the behavior of hydrogen released from biomass pyrolysis[J].4)掃描電鏡結果表明，原料經熱解后，表面結構被Journal of Shandong University of Technology: Sci & Tech,破壞，部分區域塌陷形成了凹凸不平的表面形態，隨著2006, 20(5): 41 -43. (in Chinese with English abstract)熱解溫度的繼續升高，產生了明顯的孔隙結構。原料自I7] 馬隆龍，顏涌捷，孔曉英，等.稻殼和木粉在內循環流化身結構特性對熱解炭的表面形貌影響較大，花生殼炭與床氣化爐中氣化實驗研究[].農業工程學報，2006, 22(增木薯莖稈炭表面孔隙結構比稻殼炭更為發達。刊1): 151-154.Ma Longlong, Yan Yongjie, Kong Xiaoying, et al. Study on[參考文獻]gasification experiment of wood powder and rice husk in[] Caputo A C, Palumbo M, Pelagagge P M, et al. Economics ofinternally circulating fluidized bed gasifier[J]. Transactionsbiomass energy utilization in combustion and gasificationof the Chinese Society of Agriculture Engineeringplants: Effects of logistic variables[J]. Biomass an(Transactions of the CSAE), 2006, 22(Supp 1): 151-154. (inBioenergy, 2005, 28(): 35-51.Chinese with English abstract)[2]:蔡曉峰， 張濤生物質熱解技術的現狀、發展趨勢及研究[J].8] 施建軍，鮑巍濤.生物質連續裂解能源轉化工藝與裝置實工業鍋爐，2011(2); 10-14.驗研究[D].安徽化工，2008， 34(5): 25-28.Cai Xiaofeng, Zhang Tao. Current status and developmentShi Jianjun, Bao Weitao. Experimental research on biomass第15期王明峰等:無軸螺旋連續熱解裝置上的生物質熱解特性pyrolysis set for energization[J]. Anhui Chemical Industry,[17] Sohi S, Loez-Capel E, Krull E, et al. Biochar's roles in soil2008, 34(5): 25- 28. (in Chinese with English abstract)and climate change: A review of research needs[R]. CSIRO9] 王明峰，蔣恩臣，李柏松，等.稻殼連續熱解特性研究[D].Land and Water Science Report, 2009.太陽能學報，2012, 33(1): 168-172.[18] OLaughlin J, McElligott K. Biochar for Environ-mentalmanagement: science and technology[J]. Forest Policy andWang Mingfeng, Jiang Enchen, Li Bosong, et al. Study onEconomics, 2009, 11(7): 535 - 536.continuous pyrolysis of rice husk[J]. Acta Energiae SolarisSinica, 2012, 33(1): 168- 172. (in Chinese with English[19]曹青，鮑衛仁，呂永康，等.玉米芯熱解及過程分析[J].燃abstract)料化學學報，2004， 32(5); 557 -562.[10] 袁艷文，田宜水，趙立欣，等.臥式連續生物炭炭化設備Cao Qing, Bao Weiren, Li Yongkang,研制[J].農業工程學報，2014， 30(13): 203- -210.reaction mechanism analysis of corncob[J]. Journal of FuelChemistry and Technology, 2004, 32(5): 557- 562. (inYuan Yanwen, Tian Yishui, Zhao Lixin, et al. Design andChinese with English abstract)manufacture of horizontal continuous biomass carbonizationequipment[]. Transactions of the Chinese Society of[20]夏祖章，張百良，余泳昌，等農業生物質裂解試驗研究[J].Agriculture Engineering (Transactions of the CSAE), 2014,農業工程學報，1995， 11(3): 31-37.30(13): 203 - 210. (in Chinese with English abstract)Xia Zuzhang, Zhang Bailiang, Yu Yongchang， et al.[11] 熊素敏，左秀鳳，朱永義.稻殼中纖維素、半纖維素和木Experiment study on the pyrolysis of agricultural Biomass[J].質素的測定[D].糧食與飼料工業，2005(8): 40-41.Transactions of the Chinese Society of AgriculureEngineering (Transactions of the CSAE), 1995, 11(3): 31-Xiong Sumin, Zuo Xiufeng, Zhu Yongyi. Determination ofcellulose, hemi cellulose and ligin in rice hull[J]. Cereal & Feed37. (in Chinese with English abstract)[21] Muller Hagedorn M, Bockhorn H. Pyrolytic behaviour ofIndustry, 2005(8): 40-41. (in Chinese with English abstrac)different biomasses (angiosperms) (maize plants, straws and[12] 范鵬程，田靜，黃靜美，等.花生殼中纖維素和木質素含wood) in low temperature pyrolysis[], Joumal of Analytical量的測定方法[D].重慶科技學院學報:自然科學版，2008,and Applied Pyrolysis, 2007, 79(1): 136- 146.10(5): 64-65， 67.22] 閆桂煥，孫立，孫奉仲，等，玉米秸和稻殼熱解產物的分Fan Pengcheng, Tian Jing, Huang Jingmei, et al. On the布規律[J].燃燒科學與技術，2010， 16(4); 358- 362.determination of cellulose and lignin of peanut shells[J].Yan Guihuan, Sun Li, Sun Fengzhong, et al, DistributionJournal of Chongqing University of Science and Technology:properties of pyrolrsis products of corn stalks and riceNatural Science, 2008, 10(5): 64- 65, 67. (in Chinese withhusks[J]. Journal of Combustion Science and Technology,English abstract)2010, 16(4): 358- 362. (in Chinese with English abstract)[13] Han L P, Steinberger Y, Zhao Y L, et al. Accumulation andpatitioning of nitrogen, phosphorus and potassium in23] 馬林轉，何屏，王華，等生物質熱裂解實驗研究[D]. 云different varieties of sweet sorghum[J]. Field Crops Research,南化工，2004，31(2): 9-11.2011, 120(2): 230-240.Ma Linzhuan, He Ping, Wang Hua, et al. Experiment study[14] 楊海平.油棕廢棄物熱解的實驗及機理研究[D].武漢:華on pyrolysis of biomass[J]. Y unnan Chemical Technology,2004, 31(2): 9- 11. (in Chinese with English abstract)中科技大學，2005.Yang Haiping. The Experiment and Mechanism Study on[24]呂鵬梅，熊祖鴻，王鐵軍，等生物質流化床氣化制取富Palm Oil Wastes Pyrolysis[D]. Wuhan: Wuhan Huazhong氫燃?xì)獾难芯縖J].太陽能學報，2003， 24(6);: 758- -764.University of Science and Technology, 2005. (in ChineseLi Pengmei, Xiong Zuhong, Wang Tiejun, et al. Biomasswith English abstract)gasificasion in a fluidized bed to produce hydrogen rich[15]廖艷芬，王樹榮，駱仲泱，等.纖維素快速熱裂解試驗gas[J]. Acta Energiae Solaris Sinica, 2003, 24(6): 758- 764.研究及分析[J].浙江大學學報:工學版，2003, 37(5):(in Chinese with English abstrac)582- 601.[25]呂鵬梅，熊祖鴻，常杰，等.生物質催化氣化制取富氫LiYanfen, Wang Shurong， Luo Zhongyang, et al燃?xì)獾难芯縖].環境污染治理技術與設備, 2003, 4(11):Research on cellulose rapid pyrolysis[J]. Journal of Zhejiang31- 34.University: Engineering Science, 2003, 37(5): 582 - -601. (inLu Pengmei, Xiong Zuhong, Chang Jie, et al. Potential ofhydrogen production from biomass catalytic gasification[J].[16] 許燕萍，謝祖彬，朱建國，等.制炭溫度對玉米和小麥生Techniques and Equipment for Environmental Pollution物質炭理化性質的影響[J].土壤，2013， 45(1): 73-78.Control, 2003, 4(11): 31- 34. (in Chinese with EnglishXu Yanping, Xie Zubin, Zhu Jianguo, et al. Effects ofpyrolysis temperature on physical and chemical properties of[26]郭平，王觀竹，許夢，等.不同熱解溫度下生物質廢棄物corn biochar and wheat biochar[J]. Soils, 2013, 45(1): 73-制備的生物質炭組成及結構特征[].吉林大學學報:理學78. (in Chinese with English abstract)版，2014, 52(4): 855-860.222農業工程學報http://www.tcsae. org)2015年Guo Ping, Wang Guanzhu, Xu Meng, et al. Structure andbagasses-based biochar[J]. Chinese Journal of Tropicalcomposition characteristics of biochars derived from biomassCrops, 2014, 35(3): 595 - 602. (in Chinese with Englishwastes at different pyrolysis temperatures[J]. Journal of Jilinabstract)University: Science Edition, 2014, 52(4): 855 一860. (in28] 李飛躍，謝越，石磊，等.稻殼生物質炭對水中氨氮的吸Chinese with Engish abstract)附[D]環境工程學報，2015， 9(3): 1221- 1226.[27]俞花美，陳淼，鄧惠，等蔗渣基生物質炭的制備、表征Li Feiyue, Xie Yue, Shi Lei, et al. Adsorption of ammoni及吸附性能[J].熱帶作物學報，2014, 35(3); 595 - 602.nitrogen in wastewater using rice husk derived biochar[J].Yu Huamei, Chen Miao, Deng Hui, et al. Preparation,Chinese Journal of Environmental Engineering, 2015, 9(3):characterization andadsorption performance of1221 - 1226. (in Chinese with English abstract)Biomass continuous pyrolysis characteristics on shaftlessscrew conveying reactorWang Mingfeng, Wu Yujian, Jiang Enchen*, Chen Xiaokun(College of Materials and Energy, South China Agricultural University, Guangzhou 510642, China)Abstract: Technology of continuous pyrolysis is an effective method of disposing biomass, and the shaftless-screw-conveyingpyrolysis reactor, which is a kind of device with great development prospects, can not only reduce the weight of the conveyingmechanical components, but also provide effective space for the removal of volatile products. At present, there were fewresearches on the biomass continuous pyrolysis characteristics with the shaftless screw conveying reactor. So, the continuouspyrolysis of rice husk, peanut shell and cassava stalk was investigated on the shafless-screw-conveying reactor, and theproduct distribution, the pyrolysis gas components and the pyrolytic charcoal characteristics of the 3 biomasses at differentpyrolysis temperatures were analyzed. The pyrolysis characteristics were compared with the existing pyrolysis technology, andthe material adaptability of the reactor was discussed. This paper provided a theoretical basis for the determination of theprocess parameters of biomass continuous pyrolysis and the utilization of pyrolysis products of different biomass materials.The results showed that the distribution of pyrolysis products was consistent with other pyrolysis reactors. With the increase ofpyrolysis temperature, the charcoal yield decreased gradually, the gas yield increased, and the liquid yield increased firstly andthen decreased, which reached the maximum at 450C. The maximum liquid yield of rice husk, peanut shell and cassava stalkwas 35.24%, 33.04% and 31.94% respectively. The gas yield and liquid yield presented a competitive relationship. Fordifferent bio-materials, the order of the charcoal yield from high to low was: rice husk > peanut shell > cassava stalk, the liquidyield from high to low was: rice husk > peanut shell > cassava stalk, and there were contrary rules between the gas yield andthe liquid yield. The pyrolysis gas was mainly composed of CO2, CH4, H2, C2H4 and CO and the gas component content wasinfluenced by temperature greatly. With the increase of reacting temperature, the content of the combustible gas rose, andnon-combustible gas components declined. The relative content of combustible gas in pyrolysis gas reached 75% at reactiontemperature 650C. Different bio-materials had litte effect on the composition and content of the gas. The industrial analysisresults of the pyrolysis carbon were related to that of the raw materials. With the pyrolysis temperature increasing, the volatilecontent of the pyrolysis charcoal decreased gradually, and the ash and the fixed charcoal content increased. There weredifferences of the functional groups among different kinds of charcoals, the surface functional groups of peanut shell charcoalwas more abundant than that of rice husk charcoal. In the 3 kinds of charcoals, the highest contents of volatile, ash and fixedcarbon were obtained from cassava stalk charcoal, rice husk charcoal and peanut shell charcoal respectively. The structurecharacteristics of raw material had a greater influence on the surface morphology of carbon. The surface functional groups oflow-temperature-pyrolysis charcoal were very rich, the type of the surface functional groups reduced gradually with thepyrolysis temperature increasing. The surface structure of biomass materials continued to be destroyed, and pore structureappeared when the pyrolysis temperature increased. The structure characteristics of raw material had a significant influence onthe surface morphology of carbon, and the surface pore structure of peanut shell charcoal and cassava stalk charcoal was morethan rice husk charcoal.Key words: biomass; pyrolysis; straw; shaftless screw conveying reactor; product distribution; pyrolysis gas components;characteristics of pyrolytic charcoal
